The HE-8XLR Hum Eliminator from Ebtech is an eight channel rack mount unit, designed to eliminate 60 cycle hum caused by ground loops. It is also designed to convert unbalanced lines to true balanced lines, since unbalanced lines are more susceptible to picking up electrical noise and RF interference.
The HE-8XLR Hum Eliminator prevents ground loop antennae from forming and picking up AC hum. AC hum and noise are almost always caused by a loop antenna effect across signal lines between two or more pieces of gear, or by long unbalanced cables picking up noise. Loop antennae are basically a type of radio antenna, which tend to pick up the 60Hz (and harmonics) AC signal being broadcast by a building's electrical current. These loop antennae are closed circuits usually along the ground wires and hence are commonly called ground loops.
Unbalanced signals are more susceptible to picking up electrical noise and RF interference than balanced signals are. The longer the unbalanced cable, the greater the chance of a problem. The
HE-8XLR Hum Eliminator is one of the most cost-effective ways to convert between unbalanced signals and true balanced signals.
- Eliminates AC hum/60Hz buzz and noise quickly and easily
- Breaks grounds loops safely, while leaving all signal grounds intact
- Automatically translates signal voltages to match differences in ground potentials, avoiding clipping
- Converts automatically back and forth between balanced and unbalanced lines at either end
- Completely passive design with audiophile quality components assures the best possible noise and distortion performance
Ebtech HE8 8-Channel Hum Eliminator Rack Technical Description
Frequency response: 20Hz to 70kHz plus or minus 0.5dB
Distortion: less than 0.005% THD @ 1kHz
Crosstalk: better than -97dB
Maximum source impedance: 1k0hm
Minimum load impedance: 10k0hm
2-year warranty
Ebtech quality and reliability
Made in the U.S.A.
Condition | New |
---|---|
SKU | EBT-HE-8XLR |
UPC | 614859201060 |
Weight | 5.000000 |
